3D StereoPRO, protection marking IP67

An air proof outdoor stereo counter 3D MEGACOUNT

A perfect solution for counting people in parks and open spaces. The sensor can be supplied together with a Wi-Fi scanner and a Bluetooth module

3D counter outdoor

Small size: the dimensions are 160mm х 87mm х 47mm (6.3in х 3.4in х 1.8in)

3D counter outdoor4

Mounted to any flat surface using mounting brackets

3D counter outdoor3

Connected via a single UTP cable with a feedthrough connector on one of the sides

3D counter outdoor1

Here you can see how the 3D outdoor counter deals with shadows and unstable lighting outside, all while accurately detecting people:



CHARACTERISTICS

Installation Height From 2.4m to 6m
Accuracy  Up to 100%
Technology 3D Stereo
iBeacon (optional module) Simultaneously iBeacon, AltBeacon, Eddystone-UID, Eddystone-EID, Eddystone-URL
WiFi Scanning (optional module) Detects and records MAC addresses of mobile devices
Frame Rate 25 FPS
Software DSP BIOS
Storage Space 8 Gb, nonvolatile
Sensors CMOS, supporting HDR
Data Recording Real time
Filters Height filter
Employee Exclusion Yes
Video Analysis Customer routes, heatmaps
Conversion Counting passersby
Protocols FTP, SNTP, DNS, HTML, TFTP
Data Export Formats TXT, CSV, XML, JSON, JPG
Interface  10/100 Mbit Ethernet PoE
Software Upgrade Automatic TFTP, HTTP
Cooling Fanless
Dust Protection IP67, air proof cover
Power Supply Built-in PoE 48 V
Dimensions 160mm х 87mm х 47mm
Service Life > 20 years
Warranty 1 year

Manufacturer

MEGACOUNT



3D-PRO TECHNICAL DESCRIPTION

×
